COMMAX Door Camera DRC-4CGN2
- حساس الإضاءة
- موديل خارجي
- نوع يثبت على الحائط
- للتحدث والمكالمات المنزلية
- وحدة إضاءة ابيض مدمجة
المواصفات الفنية
Features
- Built-in pin-hole camera
- Built-in illumination sensor
- Both outdoor and indoor use (not waterproof)
- Surface-mounted type
- House call and talk
Specification
- Power source: 12V (from monitor)
- Wiring: 4 wires (polarity) to a monitor / 2 wires (non-polarity) to a electric door lock
- Video Transmission Standard: NTSC
- Image sensor: Color C-MOS (1/4″)
- Call mode: Full Duplex
- LED: Built-in white LED (activated at night)
- Camera Angle: (H) 47º, (V) 34º
- Angle Adjustment: Fixed
- Operating Temperature: -10ºC ~ 40ºC
- Minimum Illumination: 0.1 LUX (up to 300mm in front of the camera)
- Distance between door camera and monitor (TIV cable): 28 meters (Ø0.5) / 50 meters (Ø0.65) / 70 meters (Ø0.8) / 115 meters (Ø1)
- Dimensions (mm): 87.5 (W) x 120 (H) x 21 (D)
- Also available with video doorphone kits
Installation Position
